AEM TestPro

Certifier copper and fibre optical OLTS

Designed for the Installers and System Integrators

The TestPro CV100 multifunction certifier is a versatile solution specifically designed to quickly and easily verify and ensure that your network infrastructure complies with construction standards and new communication technologies.

TestPro offers the widest range of features of any other test equipment available, allowing you to perform certification and/or verification on any type of network. It is a multifunctional tool because, depending on the modules it is equipped with, in addition to certifying copper links up to Category 8 and single-mode and multi-mode optical links in Tier 1 OLTS, it allows you to verify link connectivity up to speeds of 10G, analyse and measure the PoE power actually delivered by a switch, perform in-depth analyses on LAN and wireless networks, verify and display the parameters of connected devices, perform ping, traceroute and VLAN discovery tests, and analyse the quality of available Wi-Fi signals.

The TestPro multifunction certifier consists of two identical units, both equipped with touchscreen displays, which allow operators on both sides of the link to consult and analyse the tests performed. Thanks to the platform built to support test frequencies up to 3,000 MHz and a VI-2G accuracy level, it is possible to perform advanced testing of a Cat.6A link in just 6 seconds.

The mode Self-test of the TestPro CV100 is able to certify a link of Category 6A in just 6 seconds including in the checks the additional tests of TCL, ELTCTL and imbalance of resistance. Click here to watch the video of a CAT6A test in 6 seconds.

AEM Extended Care plans, available for one or three years, protect your investment against failures not covered by warranty, guaranteeing replacement of damaged adapters and annual calibration of the instrument.

Certification of copper networks

Level of accuracy 2G/VI for maximum precision in the certification of systems of cabling in CAT 5e, 6, 6A, 7, 8 Class I/II

Certification of networks in fibre optics

Certify and inspect the connections of single-mode and multimode optical fibres, locates faults with the VFL and checks the voltages on the cables optical hybrid fibre + power supply

Multi-Gigabit speed test

When connected to the network, it can verify the performance of Ethernet links up to 10G

Wireless connectivity test

Equip the TestPro CV100 with the wireless USB adapter and search, verify and analyse the performance of 2.4 and 5GHz wireless networks

Testing of wired connectivity cable

Performs wired network diagnostics by recognising and providing information on connected devices, response times, speeds and SNR values of connections

Power over Ethernet

Certifies additional parameters TCL, ELTCL and connection resistance imbalance, performs load tests up to UPOE to verify full support of PoE applications

Single Pair Ethernet

Support for the Single Pair Ethernet cabling standards with capacity to test up to 1,800 metres

OTDR

Multimode and single-mode OTDR adapters make it easy to identify the distance of any optical loss events along the link, thus enabling Tier-2 certification

Modules for
Cat. 8.1 channel certification

OLTS modules for
single-mode fibre

OLTS modules for
multimode fibre

Multi-gigabit test
modules and PoE

Test modules on
patchcords Cat. from 5E to 6A

Thanks to the availability of numerous interchangeable interfaces, TestPro is not just a tool, but a platform for measurement modular and able to expand and adapt to the needs of the installer.

TERA modules for
Cat. 8.2 certification

Modules for
M12 X-coded connections

Modules for
testing coaxial cables

Approved by leading manufacturers of cabling systems

TestDataPro is the free software for managing TestPro reports; it is available both as a version for local installation on a PC and as a cloud version, accessible at https://tdpcloud.com.

TestDataPro PC version:

  • Allows you to define work projects, group and categorise test results in a functional manner;
  • Allows you to create individual or complete reports;
  • Allows you to perform the recertification of the software of a link using a a8> limit of tests different from the standard selected for certification in the field.

TestDataPro Cloud version:

  • Allows you to upload immediately the results of the tests to your your cloud database via a wired or wireless connection;
  • Allows you to view the results of pass/fail;
  • Allows the printing of individual reports in PDF format.

See the TestPro CV100 in action

Qualification 2.5 Gigabit and validation PoE



Per ulteriori informazioni e per scaricare la scheda tecnica, vai alla pagina prodotto del TestPro CV100 K50 o del TestPro CV100 K51.
