AEM Network Service Assistant
Multifunction connectivity tester
Designed for Network Managers
The Network Service Assistant (NSA) of AEM represents the tool for qualification most advanced today on the market.
The numerous integrated features allow this tool to support IT managers, system integrators and installers in the qualification/verification phases of copper connections, both from a physical and transmission parameter point of view.
Using the Certi-Lite function, the tool can perform a single-end measurement of all the main physical and transmission parameters of a copper link, such as return loss, NEXT, attenuation, ACRF, length and shield integrity, allowing for graphical analysis of any faults detected. Furthermore, thanks to its advanced features, it allows you to check link connectivity up to speeds of 10G, analyse and measure the PoE power actually supplied by a switch, perform in-depth analyses on LAN and wireless networks, check and view the parameters of connected devices, perform ping tests, traceroute, VLAN discovery and analyse the quality of available Wi-Fi signals.
The kit consists of a passive remote terminator and a main unit featuring an ergonomic design, large colour touchscreen display and user-friendly interface that make it very easy to manage and use the NSA.
L’NSA, grazie alle numerose funzionalità di troubleshooting, diagnostica e al Certi-Lite che permette di eseguire certifiche Single-Ended delle link in conformità allo standard ANSI/TIA 1152-A, è più di un qualificatore e si identifica come strumento perfetto per IT Manager e manutentori di rete per la verifica/qualifica del supporto delle applicazioni in sistemi esistenti o nuovi dove non è richiesta la certifica dual-ended.
AEM Extended Care plans, available for one or three years, protect your investment over time by covering your Network Service Assistant against failures not covered by warranty and ensuring that any damaged adapters are replaced.
Multi-Gigabit speed test
When connected to the network, it can verify the performance of Ethernet links up to 10G
Wireless connectivity test
Equip the NSA with the Wireless USB adapter and research, verify and analyse the performance of 2.4 and 5GHz wireless networks
Testing of wired connectivity cable
Performs diagnostics of the wired network by recognising and providing information about a9> connected devices, response times, SNR values and speed. speed and values SNR of connections
Power over Ethernet
Validates the PoE link by performing a load test and verifying the actual power available on the PD side up to UPOE, displays the pairs used for power supply, measures available voltage and current, and identifies the PoE class of the PSE and PDs.
Certi-Lite, Multi-Giga
and PoE test module
Module for testing of LoopBack
on fibre multimode
Module for testing of LoopBack
on fibre single-mode
Inspection probe
for optical terminations
Thanks to its modular hot-swappable structure, the NSA is not a simple tool, but a true and proper platform of modular measure in a position to a16> expand and adapt to the needs of Installers and Network Managers.
Kit of identifiers remote
additional and probe identification cables
TestDataPro is the free software for managing the reporting of TestPro; It is available both in a local version for PC and in a cloud version, accessible at https://tdpcloud.com.
TestDataPro PC version:
- It allows you to define work projects and then group and categorise test results in a functional manner;
- Allows you to create individual or comprehensive reports;
- Allows you to perform software recertification of a link using a test limit different from the standard selected for field certification.
TestDataPro Cloud version:
- Allows you to immediately upload test results to your cloud database via a wired or wireless connection;
- Allows you to view pass/fail results;
- Allows the printing of individual reports in PDF format.
Watch the NSA in action
Kit for identifying a link
loopback test on fibre optics
