Cabling training course

Cabling training course

This course allows to achieve the status of “Accredited Installer of CCS® cabling systems” and to apply for the Extended Warranty on structured cabling carried out according to the terms and conditions defined in the application form.

In the two days of study, the course provides the installer with theoretical and practical knowledge on the design and installation of the structured copper cabling system and the fiber cabling system. Each day is divided into two main sessions: the theoretical part covers the regulatory and planning aspects, while the practical part focuses on the installation aspects with the creation of copper and fiber links , certifications tests and problem solving.

Back to Qubix Academy Subscribe

Attestato_Cabling_ENG

1° Day

CCS® Accredited Installer

2° Day

CCS® Accredited Installer

CABLING
training course

Welcome / Opening Session / Agenda of the day

The copper cabling system

The concept of the structured cabling system
The rules of the structured cabling system
Structure of the Cabling System
Common topologies
Interfaces with the cabling system and components of the structured
cabling system
How to choose copper solutions
Copper cables
Plugs, modules and accessories
Connection methodologies
Electromagnetic Compatibility
Grounding and equipotential earthing wiring safeguard
Criteria for the design and installation
Distances and Applications
Management of the cabling system
Certification and testing of copper solutions
Practical connection tests
Termination demonstrations and trials
Realization of Cat.5E/6/6A links
Certification Procedures and tests
Demo field- tester for the certification of the link and parameters to
measure, store and print
Non-compliance monitoring and resolution
Forms to be added to the declaration of conformity
Conclusions

Welcome / Opening Session /Agenda of the day

The fiber optic cabling system

Definitions and optical technology
Structure of a fiber optic cabling
Standards, optical channel lengths and applications
Physical characteristics
System Components
Optical Cables
Optical Connectors
Optical Connection system
Connection methodologies of optical fibers
Test of a fiber optic system
Warranty and certification
Maintenance and enlargement
Practical connection tests
Demo fiber optic cable termination
Realization of links with multimode fiber
Certification Procedures and tests
Demo field tester for fiber certification
Parameters to measure, store and print
Non-compliance monitoring and resolution
Forms to be added to the declaration of conformity
Final test examination
Conclusions
